NVX NDA12001 Monoblock Car Amplifier 2400W Peak N-Series Class-D 1-Ohm Stable w/ Remote Bass Knob

The new NVX NDA12001 Monoblock Car Amplifier Delivers an impressive 2400W peak power and 1200W RMS at 1-ohm for powerful, clear audio, ensuring an immersive listening experience. Features speaker-level (high-level) inputs with signal sensing remote turn-on and includes a wired bass level remote control for easy adjustments on the go. Equipped with 4-way protection circuitry, including thermal, overload, speaker short, and DC offset protection, for reliable and safe operation.

• Product Highlights
  • 500 watts x 1 channel @ 4 ohms
  • 850 watts x 1 channel @ 2 ohms
  • 1200 watts x 1 channel @ 1 ohm
  • Total RMS Power: 1200 watts
  • Class D 1 ohms Stable Monoblock Amplifier
• Product Details:
  • N-Series Class D 1 ohms Stable Monoblock Amplifier
  • RMS Power Rating:
  • 4 ohms: 500 watts x 1 channel
  • 2 ohms: 850 watts x 1 channel
  • 1 ohm: 1200 watts x 1 channel
  • Total RMS power output: 1200 watts
  • LED Power/Protect Light
  • Wired bass level remote control included
  • Speaker-level (high-level) inputs (Requires adapter like the Kicker KISL)
  • Signal sensing remote turn-on
  • 4-way protection circuitry (thermal, overload, speaker short protection and DC offset)
  • Balanced differential inputs eliminate noise picked up by signal cables
  • Input sensitivity:
  • Low level and High level: 0.2 - 10 volts
  • Frequency Response: 20 - 250 Hz
  • Total Harmonic Distortion (THD): <0.1%%
  • Signal to Noise Ratio: >96 dB
  • Variable low-pass filter: 50 - 250 Hz
  • Subsonic filter: 10 - 55 Hz
  • Variable Bass Boost: 0 - 18 dB
  • 4 AWG gauge amplifier wiring kit is recommended for installation
  • Dimensions: 9.37" L x 4.42" W x 1.73" H
  • Authorized Internet Dealer
  • 1 Year Manufacturer's Warranty
  • MFR #: NDA12001
• Key Features
  • Amplifier Key Features - Bass Boost, Compact Design, Speaker Level Inputs
• Power Specifications - Subwoofer Channel
  • RMS Power @ 4 ohms - 500 watts x 1 channel
  • RMS Power @ 2 ohms - 850 watts x 1 channel
  • RMS Power @ 1 ohm - 1200 watts x 1 channel
• Power Specifications - Subwoofer Channel
  • Peak Power @ 4 ohm - 1000 watts x 1 channel
  • Peak Power @ 2 ohms - 1700 watts x 1 channel
  • Peak Power @ 1 ohm - 2400 watts x 1 channel
• Amplifier Specifications
  • Series - N-Series
  • Amplifier Class - D
  • Number of Channels - 1 - Mono
  • Total Peak Power Output - 2400 watts
  • Total RMS Power Output - 1200 watts
  • Maximum Input Gauge Size - 4 AWG
  • Minimum Impedance Unbridged - 1 ohms
  • Minimum Impedance Bridged - Not Bridgeable
  • Frequency Response - 20 - 250 Hz
  • THD at Rated RMS Power - <0.1%%
  • Speaker Level Inputs - Yes
  • Preamp Outputs - No
  • Built-in Crossover - Low-Pass (LP), Subsonic
  • Low-Pass Crossover Frequency - 50 - 250 Hz
  • Subsonic Filter - 10 - 55 Hz
  • Signal-to-Noise Ratio - >96 dB
  • Bass Boost - 0 - 18 dB
  • Remote bass/level controller - Yes
  • Strappable - No
  • Sonic Certified Amplifier - Yes
  • Amp Bluetooth Connectivity - No
  • Hi-Res Certified - No
  • Low-Level Input Sensitivity - 0.2 - 10 volts
  • High-Level Input Sensitivity - 0.2 - 10 volts
• What is in the box?
  • Paperwork - User manual
  • WITB: Amplifiers - Amplifier, Wired gain knob (wire separate), Gain knob wire, Mounting screws (4), Allen wrenches (2)
• Warranty and Return Policy
  • Parts Warranty Duration - 1 year
  • Labor Warranty Duration - 1 year
  • Warranty Provider - Manufacturer
